Piston Filler / LPF-50/250/500/1000/2000/5000

Description

Introduction:

Pneumatic filig machine is an automatic flling system, which uses compressed air as power and is made up of precision pneumatic components.

The structure is simple, reliable and convenient adjustment.

lt’s suitable for liquid filling and floor type.

The material contact part is 304 stainless steel.

Part of the air cylinder is with brand Airtac.

Product Detail:

Specification:

Model LPF-50 LPF-250 LPF-500 LPF-1000 LPF-2000 LPF-5000
Voltage (VHz) AC 220/50or110/60
Power (W) 20
Gas Pressure (Mpa) 0.4-0.6
Filling Range (ml) 5-50 50-250 100-500 200-1000 300-2000 500-5000
Filling Capacity(times/min) 10月18日
Filling Accuracy ≤1%
External Dimensions (LxWxH)(cm) 90X50X105 90x50X105 100X50X105 110X50×105 112X50X105 130X50X105
Net Weight (kg) 23 24 35 40 43 50
