Introduction:
BS-A series shrink tunnel adopts hot wind & down-cyclone structure, intelligence temperature control, and AC variable speed regulation.There are two optional conveyors, including Teflon belt type and roller type.
Features:
Both the height of the tunnel and shutters on the two sides are adjustable.Shrinkwrapping machine BS-4525A adopts single hot wind tunnel.
Application:
BS-A series shrink tunnel are applied to heat shrinkable film such as PVC, POF, PP etc,
Product Detail:
Specification:
| MODEL | BS-3020A |
| Voltage(V/Hz) | 220/50 380/50(3PH) 220/60(3PH) |
| Power(kw) | 5.1 |
| Loading(kg) | 10 |
| Speed(m/min) | 0~10 |
| Tunnel Size (LxWxH)(mm) | 900×300x(50-200) |
| External Dimensions(LxW*H)(mm) | 1200×500×1050 |
| Net Weight(kg) | 60 |
