5 Advantages and 4 Troubleshooting Methods of Automatic Labeling Machine You Must Know

The wide application of labeling machine has made more and more people pay attention to the automatic labeling machine,that way,its function is also constantly improving.

labeling

At present, automatic labeling machine has been widely used in medicine, food, daily chemical industry, and has obtained good market feedback.

Get to know the advantages of automatic labeling machine will

Small size

The volume and floor area of the automatic labeling machine are very small, which can save the cost of workshop infrastructure for pharmaceutical enterprises, and can also be matched with the filling machine to form a complete production line.

High production efficiency

Compared with manual labeling, automatic labeling machine as long as less human resources and workshop area can carry out uninterrupted work, and has higher production efficiency and return efficiency, saving material costs. In addition, the labeling accuracy of the automatic labeling machine is also very high, basically no error.

Long service life

The automatic labeling machine is generally made of 304 stainless steel and controlled by PLC. It is easy to operate and clean. Labeling machine equipment experts said that the full-automatic labeling machine is corrosion-resistant, not easy to rust, has a long service life, all parts and components, solid structure, long time will not fall.

It has a wide range of applications. As mentioned above, automatic labeling machine is widely used in medicine, food, daily chemical industry and other industries. Even cosmetics can be labeled with automatic labeling machine, including bar code, two-dimensional code, anti-counterfeiting label and so on. Industry insiders said that the emergence of automatic labeling machine simplifies the previous production process.

labeling-1

High performance and cost performance. Someone once calculated an account: if a fully automatic labeling machine is 60000, its service life is 10 years, and it costs only 500 yuan per month. The salary of an ordinary employee is 2000 yuan, which is 240000 yuan in ten years. As a result, the emergence of automatic labeling machine has brought great benefits to the production and packaging line.

Although the full-automatic labeling machine has many advantages, like other equipment, it also has the time of failure. In case of failure, it can be adjusted from the following four aspects.

Adjustment of cot and scraper.

It is reported that there is no gap between the rubber roller and the rubber scraper in the whole length. Once there is a gap, the rubber scraper should be adjusted by adjusting the eccentric screw. Practice has proved that when the gap between the cot and the standard plate is between 0.1 mm and 0.2 mm, it is more appropriate.

This can be achieved by adjusting the bearing seat at the lower part of the cot, or the bearing at the upper part of the cot if necessary.

Adjustment of brush pressing device.

The overlapping gap of the brush across the container is 10 mm-15 mm for a single brush, 5 mm-10 mm for a combined brush, and 1 mm-2 mm for the cleaning brush from the sponge. In terms of head adjustment, the head should be 200 mm lower without bottle than with bottle.

Adjustment of label box.

The gap between the label paper and the label box is between 0.8 mm and 1 mm.

If the gap is too large, it is easy to cause the label paper to shift in the label box, resulting in the phenomenon of oblique label.

If the gap is too small, it will appear the phenomenon of poor push mark.

Adjustment of bottle feeding star wheel, bottle discharging star wheel and bottle feeding screw rod.

When adjusting the bottle feeding star wheel, bottle discharging star wheel and bottle feeding screw rod, the marked bottle pressing head shall prevail.

When the bottle pressing head is just over the bottle, adjust the star wheel so that the bottle is in the middle of the star wheel groove;

When the bottle is in the middle of the star wheel groove, adjust the screw rod so that the bottle side of the screw rod is close to the bottle;

When the bottle pressing head is just raised, adjust the star wheel so that the bottle is in the middle of the star wheel groove.
