NJP-7500C Fully Automatic Capsule Filling Machine



NJP-7500C Fully automatic capsule filling machine is our company after years of careful research, independent research and development of a new hard capsule sealing equipment, and has independent intellectual property rights and a number of invention patents. The equipment can be used for sealing hard capsules filled (liquid, granule, powder, etc.) with glue, so that the products are always in a sealed state in the process of packaging.

1. NJP-7500C is the equipment with the highest output in China;

2. The equipment is fully enclosed, with 12 workers’ rotary table and flling module arranged with 58 holes in four rows;

3. The whole machine is equipped with the automatic stop system of gate control and alarm, which can realize the function of electronic signature printing and industrial Ethernet connection;

4. The lower module has one-way movement with two shafts, and the imported polyurethane sealing ring prevents dust from entering the rotary plate;

5. The main engine is equipped with intelligent remote control,inching, test, easy to operate, to ensure personnel safety;

6. Automatic vacuum feeding and vacuum capsule can be installed,and the control system is operated by touch screen.


Model NJP-7500C
Output 46800 Granule/Hour
Machine Weight 3500Kg
Machine Dimensions 1450x1920x2400mm
Power Supply 380/220V 50Hz
Motor Power 14Kw
No.of segment bores 58holes
Vacuum 0.4-0.6Mpa
Dust 24.5Kpa 210m3/h
Nosie <75DB(A)
Making rate Empty capsule 99.9% Full capsule over 99.8%
Suitable for capsule 00#-5#
Filling error ±3%±4%
