NJP-1200D Automatic Capsule Filling Machine

video:

Introduction:

NJP-1200D automatic capsule filling machine produced by our company is the innovative product of the third generation. It not only covers all the functions and effects of the domestic capsule filling machine of the same model, but also has six pieces of innovation, two of which has been issued the utility model patent certificate by the national intellectual property administration, PRC at May 11, 2016. The innovative NJP-1200D automatic capsule filling machine has advantages of higher production efficiency and longer service life, and has been well received by customers at home and abroad..

Feature:

  1. In order to improve the quality and production efficiency of this model, we have made significant improvement on the original 1200Dautomatic capsule filling machine. The overall machine size has been enlarged, where the main machine dimension is changed to1200×1000×2150mm.
  2. For ensuring the device quality and production effects: we have selected bigger high precision dividing box, which is better than 1200Dautomatic capsule filling machine of the same model produced by other companies in domestic industry, who usually use the configuration of 83DS and 83DS cam dividing box, and whose disadvantage is that the filling speed is limited at about 900pcs capsule per minutes in proper working condition. Forcibly increasing the filling speed to about 1000pcs capsule per minutes and continuing the working condition for these machines may cause breaking of the input and output shafts and the subsequent operation stopping. Unlike other companies, we use cam dividing configuration of 100DS, and we are the first one in domestic market to use the 100DS. Although the production cost increases, we have significantly enhanced the device’s production efficiency and service life. Its filling speed has been raised up to about 1100pcs capsule per minutes. Due to these advantages, it has been widely received by customers at home and abroad.

Specification:

Model NJP-1200D
Filling capacity 72000pcs per hour
Weight 1000Kg
Dimension 1100×910×2100mm
Power supply 380/220V   50Hz
Total power 5.5KW
Segment bores 9 holes
Vacuum 40m3/h-0.04-0.08Mpa
Dust collector 24.5Kpa   210m3/h
Air compression Air consumption 5m3/h   Pressure 5-7Kg
Operating noise <75DB(A)
Filling percentage Empty capsule 99.9%   filled capsule 99.8%
Capsule size 00,0,1,2,3,4,5#   safety capsule A-E
Filling accuracy Western medicine ±3%   Chinese medicine ±4%
Suitable for Powder, Granule, Pellet, Tablet.
