GHL Series High Speed Mixer/Granulator



GHL high speed mixing granulator is a high efficiency equipment that can mix different powder materials and granulate granule in one procedure. It is widely used for pharmaceutical industry, foodstuff industry and chemical industry, etc.

The powder material and adhesive are mixed fully at the bottom to become humid soft material, the nit is cut through high speed crusher and become uniform granules.


1.The machine adapts horizontal cylinder structure. Its structures is reasonable;
2.Use air filled seal shaft to drive. When washing, it can be changed to water;
3. Use fluidization to Granulate and the granule is like ball. lts flowability is good;
4.Compared with the traditional process,25%) of adhesive can be reduced and the drying time can be shorted;
5. The time of mixing in dry is 2 minutes and the time of granulating is 1-4 minutes. Compared with the traditional process, 4-5 times of efficiency is raised;
6.In the same sealed container, dry mixing, humidity mixing and granulating can be finished, it is in conformity with the requirements of GMP;
7.The whole operation has strict safe and protective measures.
8.The mixing and cutting speed are controlled through frequency change, so the granules are more even.


Model Capacity Outpnt Admix speed Admix power Incise speed Incise power
GHL-50 50L 15kg/batch 200/400rpm 5.5kw 1500/3000rpm 2.2kw
GHL-150 150L 50kg/batch 180/270rpm 15kw 1500/3000rpm 5.5kw
GHL-200 200L 80kg/batch 180/270rpm 15kw 1500/3000rpm 5.5kw
GHL-250 250L 100kg/batch 180/270rpm 15kw 1500/3000rpm 5.5kw
GHL-300 300L 130kg/batch 140/220rpm 18.5kw 1500/3000rpm 7.5kw
GHL-400 400L 200kg/batch 106/155rpm 22kw 1500/3000rpm 7.5kw
