Description

Introduction:

1.The machine is cdeal for sealing small packages, which adopts constant temperature control system and stepless speed regulation mechanism.

2.lt can seal plastic films made from various materials continuously.

3.Embossing wheel and counting device are optional.

4.FR-770 series are available in three models: horizontal model (FR-770l), vertical model (FR-77OIl) and console model (FR-770Il)

Dimension:

Product Detail:

Specification:

MODEL FR-77OII
Voltage (VIHz) AC 220/50110/60
Power (W) 50
sealing Power (W) 300×2
sealing Speed (m/min) 0-12(0-16)
Sealing Width (mm) 10
Temperature Range (°c) O-30o
Printing Type Steel wheel embossing wheel printing (optional)
Distance from Sealing Center to conveyor Table (mm) 20-40
Distance from Base plate to Interior Conveyor (mm) 65-85
conveyor Size (Lxw) (mm) 950×180
Max. conveyor Loading for Single Package (kg) S1
overall conveyor Loading (kg) ≤3
External Dimensions (LxWxH)(mm) 840×550×800
Net Weight (kg) 29
