CO2 Laser Coding Machine FC-100B

Next

CO2 Laser Coding Machine FC-100A

Next Product Image

CO2 Laser Coding Machine FC-100D

Description

The thin laser beam of Raymond FC-100D laser coding machine can process material with small consumption and affected heat zone, and various fine and complicated patterns can be marked on very tiny surfaces. It can mark on a variety of non-metal materials, especially for high hardness, high melting point and brittle materials.

Description:

Use laser to mark logo or photo on electronic products, daily necessities, packaging, gift, craft, auto parts, digital products, communication goods, building materials, electrical appliances, kitchenware, jewelry, sanitary ware, medical apparatus,photovoltaic product, commodity, hardware, and so on.

Process Materials:

Non-Metal( Suitable for leather, cloth, paper, wood, acrylic, crystal, ceramics, marble, composite materials and other non-metallic materials)

Industry: widely used in embroidery, trademark, buttons, glasses, clothing, sanitary ware, glass products, advertising materials, food and beverage packaging, pharmaceutical packaging, components, handicraft processing, stone, paper packaging, plastic products, paper labels, plastic resin, bamboo wood crafts, PCB board etc.

Compact design and fast installation

Easy to be integrated at any position of the production line

More further environmental protection and energy saving

Un-contact processing, more environmental protection, low er power, fast laser marked and cost economy

Easy to use and Excellent compatibility

Simplicity of operation, easy to use, powerful anti-jamming performance, enough memory, multiply input and output interface, use with automatical anti-counterfeit and anti-disorder system

Adopt import laser, more safer and faster

Machine Model FC100-20 FC100-30 FC100-50
Laser Power 20w 30w 50w
Laser Wavelength Standard 10.6um optional 10.2 or 9.3um Standard 10.6um optional 10.2 or 9.3um Standard 10.6um optional 10.2 or 9.3um
Fiber Length 2.5m 2.5m 2.5m
Cable Length 1.5M or Customize longer
Laser Unit Using Life 30000-40000 Hours 30000-40000 Hours 30000-40000 Hours
Marking Speed ≤12000mm/s(Character marking speed and production line speed depend on material, character size and desired marking quality)
Marking Speed 2-3 digital(2*3mm)/0.01s 3-5 digital(3*5mm)/0.01s 3-5 digital(3*5mm)/0.01s
Marking Deepth ≤0.5mm ≤0.5mm ≤0.5mm
Min.Line Width 0.012MM 0.012MM 0.012MM
Min.Character Height 0.15MM 0.15MM 0.15MM
Marking Filed F160/110*110mm,F210/145*145mm,F254/175*175mm, or Customize longer
Power Supply 220V/110V 50HZ/2A 220V/110V 50HZ/2A 220V/110V 50HZ/2A
Power Consumption 800W/Hour 800W/Hour 800W/Hour
Cooling Air Air Air
Positioning Visible Red Power Visible Red Power Visible Red Power
Operating Temperature 0°C-40°C 0°C-40°C 0°C-40°C
