SIMPLE, POWERFUL, AND RELIABLE
U2 Series is the first legacy ultra-compact all-in-one inkjet printer specifically for simple and low volume production line. It’s simplicity design allows user self-installation with no requirement of technical experiences. ANSER thermal inkjet technology provides small business users reliable high resolution coding without regular maintenance and technical supports. A true maintenance-free and service-free coding solution.Tenth of thousands installed worldwide, with proven track record on reliability and stability. It’s small, yet it’s powerful.
ANSER provides wide range of ink portfolio to meet your substrate application requirement, whether it’s corrugated boxes, plastic bottles, metal, wood, glass or direct food printing.
ANSER 1″ printhead provides non-stitched 25.4mm print height, a true maintenance free, and cost saving alternative for case labeling.
Compact enough to be integrated in most production line tight spots with easy installation.
ANSER thermal inkjet technology provides business owner a true maintenance free and service free coding solution, with no hidden costs.
|Printer model||Smart ONE|
|Display||3.5″ color LCD with LED backlight|
|Input Device||Pocket-sized IR remote keypad|
|Print Engine Technology||Thermal Inkjet|
|LED Indicators||Alarm, Ink Low, Print, Run, Remote on/off|
|Available Languages||English, Chinese (Traditional), Chinese (Simplified), Japanese, Russian, Korean, German, Portuguese, Spanish, French, Italian,
Turkish, Hungarian,Slovak, Czech, Swedish, Romanian, Serbian Latin, Serbian Cyrillic, Bulgarian, Polish, Vietnam
|Mounting Orientation||Horizontal or downside|
|Max. Printing Resolution||400(h) x 600(v) dpi *Horizontal dpi varies from encoder setup|
|Max. Printing Speed||60.96 m/min at 300 dpi setting|
|Max. Printing Distance||Recommended 6mm from nozzle to surface|
|Message Height||Up to 25.4mm (1 inch)
Selectable font size: 2.0mm, 2.8mm, 3.6mm, 5.4mm, 7.2mm, 9mm, 10mm, 11mm, 12.8mm, 16mm, 20mm, 22mm, 25.4mm
|Print Capabilities||Text, String, Logo, Shift, Counter, DateTime, Expiration Date, Barcode|
|Barcodes||Code-128, ITF-14(SCC-14), NVE(SSCC-18), EAN-13, EAN-14, EAN-8, EAN-128, PDF417, Data Matrix, QR Code, DUN-14, GS1 Datamatrix,
GS1 DataBar, GS1 DataBar EXP,GS1 QR CODE, UPCA, UPCE, Codabar, Aztec Code, INTER25, CODEBAR, Code-39
|Message Storage Capacity||Store up to 999 messages|
|Input/Output||RS-485, RS-232, USB, Wi-Fi & Ethernet|
|Power Adapter||Input AC 100V~240V, 50/60Hz|
|Operating Temperature||5°C – 40°C (41°F – 104°F)|
|Dimensions||114 (L) x 76 (W) x 60 (H) mm|
|Weight||0.49 kgs (1.08 lbs) – Cartridge and brackets not included|
|Standard Accessories||Bracket set, power adapter, USB disk, remote control|
|Optional Accessories||300 dpi & 400 dpi Encoder kit, Photocell kit, Wi-Fi dongle, Ethernet dongle, U2 Bracket Plus, RS-485 to USB converter, Smart I/O kit, Clock stabilizer|
|PC Software||Message Pro II, Net Commander|
|Printer Control Protocol||ANSER U2 Net Protocol|
